Artwork Protection

Demander un échantillon

tecnilith® Artwork Protection Film prevents scratches and chemical damage to printed circuit artwork that can occur during panel exposures and cleaning.

Avez-vous une question? Contactez-nous

Artwork Protection Film (APF)

Description:
Unique slipcoat/hardcoat combination enables the PCB manufacturer to better safeguard artwork from scratches and chemical damage that could result from use or cleaning as well as an ultra non-stick surface designed for liquid photoimageable soldermask and other direct-contact-imaging systems. Our film has superior barrier protection and will not interfere with light transmission and is easily applied with standard laminating equipment.

Benefits:

  • Slipcoat: Prevents phototool sticking. Easy registration.
  • Hardcoat: Safeguard artwork from scratches and chemical damage
  • Optically Clear: Fine-line resolution.100% U.V. transmission. High level anti-static properties.
Product Base thickness Adhesive Hard Coat / Slip Coat Length Width Standard width

TEC6.0L

6 µm

2 µm

1 µm

150 m

From 254 to 711 mm

508, 559 and 610 mm

TEC3.5L
(for<75 µm lines)

3.5 µm

2 µm

1 µm

150 m

From 254 to 711 mm

508, 559 and 610 mm

Special versions:
L: Slipcoat
LA: Slipcoat + frequent removal
LV: Slipcoat + vacuum drawing
