ELPEGUARD® Conformal Coating
Request a sampleFrom coatings for the manufacture of printed circuit boards and the protection of assembled printed circuit boards/electronic components to integrated coating technology solutions, Peters is a global leader in the field of electronics-related high-tech coatings for automotive electronics, aerospace engineering, industrial electronics, medical technology, LED applications and other industries.
Have a question? Get in touch
ELPEGUARD® conformal coatings are used to protect and insulate assembled pcbs so that they can fulfil higher requirements regarding reliability and service life.
ELPEGUARD® Thin film coatings:
Solvent-containing or aqueous 1- and 2-pack “ready-to use” systems with very good resistance against moisture and condensation, thus enabling an excellent corrosion protection for assembled pcbs (e.g. e-corrosion and migration), typical dry layer thickness < 80 µm, suitable for coating flexible circuits (“flex-to-install”); can be soldered through for repair or mechanically removed (blasting method); coloured-transparent, opaque or fluorescent adjustments permit a simple checking of the coating layer for completeness with daylight or UV light (black light).
ELPEGUARD® Thick film coatings:
solvent-free 1-pack systems with excellent chemical resistance; typical dry layer thickness > 80 µm, thus providing excellent protection even in critical weather conditions; the fluorescent adjustment permits an easy and reliable check of the coating result under UV light (black light), can be removed mechanically for repair purposes.
| Coating thickness | Serie | Type | UL94 | Operating Temp | Features | Drying | Datasheet |
|---|---|---|---|---|---|---|---|
|
< 80µm |
SL 1301 ECO-FLZ |
Modified PU |
V0 |
– 40 to + 140 °C |
Automotive applications. |
At room Temp. |
|
|
< 80µm |
SL 1305 AQ-ECO |
Modified PU |
V0 |
– 40 to + 130 °C |
Aqueous. Good yellowing resistance. |
Quick at room Temp. |
|
|
< 80µm |
SL 1307 FLZ |
Acrylic |
V0 |
– 65 to + 125 °C |
Automotive application. Removable for repair. |
Quick at room Temp. |
|
|
> 80 µm |
DSL 1600 E-FLZ |
Twin cure PU |
V0 |
– 65 to + 130 °C |
Quick processing. Solvent-free / VOC-free. Cross-linking reaction even in shadow zones. |
UV |
|
|
< 3000 µm |
DSL 1705 FLZ |
Silicone |
V1 |
– 40 to + 200 °C |
Elasticity for thermal and mechanical constraint |
15 min @ 110 °C |
|
|
< 300 µm |
DSL 1706-FLZ |
Silicone |
V0 |
– 40 to + 200 °C |
Quick at room Temp. |
||
|
Dam & fill |
EH13.401 FLZ-UV |
Acrylate |
–40 °C to +125 °C |
Dispensable to build dam to prevent conformal coating penetration |
UV |
