MTS & RFID

Request a sample

Comprehensive range of screenprintable conductive silver and carbon inks with dielectric inks for Membrane Touch Screen & RFID applications.

Have a question? Get in touch
Application Composition Product Code Features Resistivity PDF
Silver & Silver based Inks

Printed Electronics

• Silver

5025

All round performance

12 – 15 mΩ/sq/mil

Printed Electronics, RFID

• Silver

5028

High conductivity

< 12 mΩ/sq/mil

Printed Electronics, RFID

• Silver

5000

High conductivity

<10 mΩ/sq/mil in IR curing (o/w <15 mΩ/sq/mil)

Printed Electronics, RFID

• Silver

5065

Very high conductivity

5 – 10 mΩ/sq/mil

Printed Electronics, RFID

• Silver

5064H

Very high conductivity

5 – 10 mΩ/sq/mil

Printed Electronics, RFID

• Silver

5029

High conductivity, thick print up to 30 µm laminated

4 – 8 mΩ/sq/mil

Printed Electronics, RFID

• Silver

PE819

High conductivity, thick print up to 30 µm laminated

4 – 8 mΩ/sq/mil

Printed Electronics

• Ag composite

PE825

Low Ag content 37%

<30 mΩ/sq/mil

Printed Electronics

• Ag composite

PE826

Low Ag content  18%

<60 mΩ/sq/mil

Touch screen

• Ag

PE830

Low temperature drying (65°C/1h or 130°C/15 minutes). Adhesion to metal, dispensable

<40 mΩ/sq/mil

Carbon Ink

Printed Electronics

• Carbon

7105

Low cost carbon

< 30 Ω/sq/mil

Printed Electronics

• Carbon

7082M

Low cost carbon

1KΩ/sq- Can be blended with 3571 or 7102

Printed Electronics

• Carbon

7102

Low cost carbon

<20 Ω/sq/mil

Prinetd electronics, RFID

• Carbon Nano-Tube

VC102

Transparent conductor, environmentally stable

100Ω/sq and 85% VLT environmentally stable

Dielectric Ink

Printed Electronics

• Dielectric

5018

Blue, UV curing, Dk 4,4 – breakdowm voltage > 500 V/mil DC

> 10 GΩ/sq/mil

Printed Electronics

• Dielectric

5018G

Green version of 5018

> 10 GΩ/sq/mil

Printed Electronics

• Dielectric

5018A



Translucent version of 5018

> 10 GΩ/sq/mil

Printed electronics, RFID

• Dielectric

ME779

Heat curable, White, Solvant based

Printed electronics, RFID

• Dielectric

8153

Heat curable, White, Solvant based

Encapsulant

Printed electronics, RFID

• Encapsulant

ME780

Heat curable, Transparent, UV filter

Printed electronics, RFID

• Encapsulant

5036

Heat curable, Transparent
